Series 36 Classic

Discontinued Model
36.1.075.0 product image
igus-icon-lupe
36.1.075.0 technical drawing
igus-icon-lupe
1 of 2
36.1.075.0 product image
36.1.075.0 technical drawing
Inner height [Hi]
Inner height [Hi]
45 mm
Max. cable diameter
Max. cable diameter
42 mm
Opening principle
Opening principle
openable from both sides
Inner width [Bi]
Inner width [Bi]
75 mm
Bend radius [R]
Bend radius [R]
75 mm
