chainflex® CF240 data cable

1 of 2

Item no.

CF240.01.03

Number of cores and conductor nominal cross-section

(3x0.14)C

Outer diameter (d) max. mm [mm]

chainflex® CF240 data cable PVC

Typical application areas

For medium duty use
Light oil influence
Preferably indoor applications, but also outdoor ones at temperatures > 5 °C
Unsupported travel distances and up to 50 m for gliding applications
Storage and retrieval units for high-bay warehouses, machining units/packaging machines, handling, indoor cranes

Guaranteed lifetime according to guarantee conditions
More Information: [Link id="13"]

Double strokes*	5 Millionen		7.5 million		10 million
Temperature,	< 10 m	≥ 10 m	< 10 m	≥ 10 m	< 10 m	≥ 10 m
von/bis [°C]	R min. [Faktor x d]		R min. [Faktor x d]		R min. [Faktor x d]
+5 / +15	12.5	15	13,5	16	14.5	17
+15 / +60	10	12.5	11	13.5	12	14.5
+60 / +70	12.5	15	13.5	16	14.5	17

* Higher number of double strokes possible - use the function of service life calculation on this page.

Guaranteed service life for this series according to guarantee conditions
Further information: chainflex® guarantee

Double strokes*	5 million		7.5 million		10 million
Temperature,	< 10m	≥ 10m	< 10m	≥ 10m	< 10m	≥ 10m
from/to [°C]	R min. [Factorxd]		R min. [Factorxd]		R min. [Factorxd]
+5 / +15	12.5	15	13.5	16	14.5	17
+15 / +60	10	12.5	11	13.5	12	14.5
+60 / +70	12.5	15	13.5	16	14.5	17

* Higher number of double strokes possible - use the service life calculation function on this page.
