drylin® N - Low profile linear guide system NK-02-17

DryLin® N low profile guide system rail

More about selected part:

Drylin® low profile linear guide system NK-02-17

More about selected part:

Dimensions [mm] - guide carriages

More about selected part:

Ordering of a complete system

Configuration in few steps:

Hint:

drylin® NK – complete set

Step 1

Static load capacity and moments of inertia of an area

Order no.	Max. rail lengths	a	C4	A3	C5=C6		h	h1	K1*	ly	lz	Weight of rail	Price / m
	[L max.]				Min.	max.				[mm²]	[mm²]	[g/m]
NS-01-17	2000	17	60	0	20	20/49,5	5,5	0,9	M3	1700	120	150	1 526,87 UAH
NS-01-17-AR	2000	17	60	0	20	20/49,5	5,5	0,9	M3	1700	120	150	1 756,08 UAH
NS-01-17-UNGEBOHRT	2000	17	60	0	20		5,5	0,9	M3	1700	120	150	1 366,92 UAH

Part No.	H	A	C	C2	K3	Spmin.	DpØmin.	Weight
	±0,35							[g/m]
NW-02-17	6	9,6	20	14	M3	2,5	5	1,7
NW-02-27	9,5	14	34	20	0	0	0	12,5
NW-02-17-P	6	9,6	20	14	M3	2,5	5	1,7
NW-02-17-LLY	6	9,6	20	14	M3	2,5	5	1,7
NW-02-17-LLZ	6	9,6	20	14	M3	2,5	5	1,7
NW-02-17-LLYZ	6	9,6	20	14	M3	2,5	5	1,7
